Khoom Description
|
Los ntawm kev ua haujlwm thiab txheej txheem |
Ntsiab nta thiab daim ntawv thov |
|
Raw Material Storage Tanks |
Siv los khaws cov khoom siv phosphoric acid rau kev siv ntau lawm. Ntev - lub sijhawm ruaj khov yuav tsum tau khaws cia. |
|
Intermediate tank / Ua haujlwm tank |
Nyob rau hauv cov kab ntau lawm, siv rau buffering, homogenization, thiab ib ntus cia ntawm cov txheej txheem txheej txheem (xws li, dilute acid tank, concentrated acid intermediate tank). Nws yog ib qho tseem ceeb rau cov txheej txheem stability. |
|
Cov khoom tiav lawm cia Tank |
Cov tso tsheb hlau luam no khaws cov khoom kawg, tsim nyog phosphoric acid, tos cov khoom xa tuaj. Cov kev xav tau muaj nyob rau hauv kev tswj xyuas cov khoom zoo (xws li concentration thiab clarity). |
|
Lub tank khib nyiab |
Siv los khaws cov nyiaj siv, qis -concentration, thiab impurity-muaj phosphoric acid uas tos kev kho lossis rov tsim dua tshiab. Lub tank no ntsib cov kev ua haujlwm nyuaj tshaj plaws thiab qhov chaw muaj zog tshaj plaws corrosive. |
|
Metering tanks los yog acid npaj tanks |
siv los ntsuas qhov tseeb lossis npaj cov tshuaj phosphoric acid ntawm cov ntsiab lus tshwj xeeb. Lawv feem ntau yog me me nyob rau hauv ntim thiab nruab nrog meej qib gauges thiab stirrers. |
|
Raws li cov yam ntxwv ntawm qhov nruab nrab |
Ntsiab nta thiab daim ntawv thov |
|
Dilute phosphoric acid tank |
Qhov no feem ntau yog hais txog phosphoric acid nrog P₂O₅ concentration hauv qab 40%, uas muaj qhov kub thiab txias tsis muaj zog, tab sis tej zaum yuav muaj impurity ions xws li fluorine thiab chlorine. |
|
Dilute phosphoric acid tank |
Qhov no feem ntau yog hais txog phosphoric acid nrog P₂O₅ concentration hauv qab 40%, uas muaj qhov kub thiab txias tsis muaj zog, tab sis tej zaum yuav muaj impurity ions xws li fluorine thiab chlorine. |
|
Thermal txheej txheem phosphoric acid tank |
Siv rau khaws cov ntshiab phosphoric acid uas ua los ntawm cov txheej txheem thermal. Nws muaj ob peb impurities, tab sis qhov siab concentration thiab kub ua rau muaj teeb meem corrosion tseem ceeb, feem ntau vim phosphoric acid nws tus kheej. |
|
ntub - txheej txheem phosphoric acid tank |
Kev khaws cov phosphoric acid uas tsim los ntawm cov txheej txheem ntub dej, uas muaj cov impurities xws li fluorosilicic acid, sulfuric acid, thiab hlau ions, nthuav tawm cov txheej txheem corrosion nyuaj thiab ua rau muaj kev sib tw loj tshaj plaws hauv kev xaiv cov khoom. |
Khoom Description
Tank Structure: Vertical flat-bottomed conical lossis domed tank, nrog rau hauv qab conical kom yooj yim ntws. Nruab nrog manholes thiab tu cov chaw nres nkoj.
Ua pa thiab kev nyab xeeb System:
Ua pa Valve: Sib npaug sab hauv thiab sab nraud lub tank siab, txo evaporation poob.
Nitrogen Blanketing System (rau cov concentrated phosphoric acid): Siv cov roj inert los npog cov kua dej, tiv thaiv kom tsis txhob ya raws, dilution, thiab corrosion.
Qhov Chaw Nres Nkoj Txuas rau Acid Mist Scrubber: Kho cov kua qaub tsis zoo.
Qib ntsuas: hom Radar (nyiam dua), hom magnetostrictive, zam kev siv yooj yim corroded hu- hom twj paj nruag.
Kev ntsuas kub: Ntau- ntsuas kub ntsuas.
Densitometer (yeem): Kev saib xyuas hauv online.
Lub tswb nrov thiab qis qis thiab cuam tshuam: tiv thaiv lub tank dhau thiab khoob.
Associated Piping: Inlet thiab qhov hluav taws xob cov kav dej, rov qab cov yeeb nkab, cov yeeb nkab ntws, nrog cov khoom sib txuam lossis hloov kho los ntawm cov khoom siv tank.
